Boom! NASA to Demolish Spacecraft in the Name of Science

Space can be sprinkled with jagged junk resulting from satellite collisions. (Image credit: Melrae Pictures/Space Junk 3D)

Work is underway to create a spacecraft that won't be rocketed into outer space but will be purposely destroyed on the ground.

DebriSat is a 110-pound (50 kilograms) satellite that's a double for a modern low-Earth orbit spacecraft in terms of its components, materials used, and fabrication procedures. But once fabricated and tested, DebriSat is doomed.

The spacecraft will be the target of a future hypervelocity impact experiment to examine the physical characteristics of debris created when two satellites collide.

NASA and the Air Force's Space and Missile Systems Center are co-sponsors of DebriSat. The NASA Orbital Debris Program Office at the Johnson Space Center in Houston is leading the effort. [Photos: Space Debris Images & Cleanup Concepts]

Impact risk assessments

Data gleaned from demolishing DebriSat will be valuable in the short- and long-term, said J. C. Liou of NASA's Orbital Debris Program Office.

"Collision fragments are expected to dominate the future orbital debris environment," Liou told SPACE.com. Therefore, he said, a high fidelity breakup model describing the outcome of a satellite collision — in terms of the fragment size, mass, area-to-mass ratio, shape, and composition distributions — is needed for reliable short- and long-term impact risk assessments.

Those appraisals deal with debris as small as 1 millimeter for critical space assets and for good orbital debris environment definition, Liou said. Some of the distributions for "large" fragments can be obtained from the U.S. Space Surveillance Network (SSN) observations. But the SSN data are limited to 10-centimeter (4 inches) and larger objects. "Laboratory-based experiments are necessary to collect data for smaller debris," he said.

As a modern satellite target, obliterating DebriSat is expected to improve the NASA standard satellite breakup model.

Laboratory-based impact tests

Liou pointed out that the Department of Defense (DoD) and NASA have conducted quite a few laboratory-based impact tests in the past. One of the key experiments supporting the development of the NASA and DoD satellite breakup models was called SOCIT, short for Satellite Orbital debris Characterization Impact Test series.

In one SOCIT ground experiment in 1992, the target was a flight-ready U.S. Navy Transit satellite built in the 1960s. But that was then, and this is now. Present day satellites incorporate many different technologies and materials than spacecraft designed over 40 years ago.

"As new materials and new construction techniques are developed for modern satellites, there is a need to conduct additional laboratory-based tests and use the new data to further enhance the breakup models," Liou said.

DebriSat is built to be busted up, designed to yield new data on on-orbit collisions. (Image credit: Mark Werremeyer/University of Florida Space Systems Group)

Integrity of the destructive outcome

A University of Florida team is designing and fabricating DebriSat for its eventual demise.

To put DebriSat together, a wide-ranging study was done of past low-Earth orbit satellite designs and missions within the last 15 years for spacecraft ranging from one kilogram to 5,000 kilograms (2.2 pounds to 11,023 pounds).

This study identified modern trends in hardware, material, and construction practices utilized in recent LEO missions. While DebriSat is an engineering model, specific attention is being placed on the quality, type, and quantity of the materials used in its fabrication to ensure the integrity of the destructive outcome.

With the exception of software, all other aspects of the satellite's design, fabrication, and assembly integration and testing will be as rigorous as that of an actual flight vehicle, according to officials involved in the DebriSat effort.

DebriSat is now slated to undergo a hypervelocity impact test in early 2014, said Norman Fitz-Coy, associate professor in the Department of Mechanical and Aerospace Engineering and director of the Space Systems Group at the University of Florida, which is in Gainesville. He is leading the university's DebriSat team.

Labor intensive exercise

A hypervelocity impact test is one in which the amount of energy experienced during a typical impact between two orbiting satellites is replicated, Fitz-Coy told SPACE.com. The test will be performed at the Air Force's Arnold Engineering Development Center in Tennessee.

Once busted up, how much work is involved in piecing together just how the satellite reacted to the impact?

"We are not actually gluing the satellite back together," Fitz-Coy said. "Rather we are characterizing — size, shape, etc. — of the fragments resulting from the impact. This is a labor intensive exercise."

NASA's Liou said that after the hypervelocity test, the University of Florida experts will collect fragments down to roughly 0.08 inches (2 millimeters) in size. That's about as long as a nickel is thick.

The dimensions of the resulting fragments will then be measured individually. That data will be delivered to NASA and the Air Force Space and Missile Systems Center.

The NASA Orbital Debris Program Office will lead the effort to analyze the data and use the information to enhance the satellite breakup model, Liou said.
